DJ41Y-160P低溫高壓截止閥
- 產品名稱:免費黃色視頻下載:DJ41Y-160P低溫高壓截止閥
- 產品型號:DJ41Y
- 產品口徑:DN15-50mm
- 產品壓力:16Mpa
- 產品材質:不銹鋼
- 聯系電話:021-51061127
- 聯系傳真:021-51062214
- Email:fashengfamen@126.com
- 聯系人:陳云非
- 聯系手機:18217570461
- QQ:203398752
- 公司名:上海閥盛閥門制造有限公司
- 帳號:03416900040048386
- 開戶行:農行上海水清南路支行
- 售后承諾:質保一年,質量三包:包修、包換、包退。
上海閥(fa)(fa)(fa)盛閥(fa)(fa)(fa)門制造有限公司主要(yao)生產DJ41Y-160P低(di)(di)(di)溫(wen)(wen)(wen)高(gao)(gao)壓(ya)截(jie)(jie)(jie)(jie)止(zhi)(zhi)(zhi)閥(fa)(fa)(fa),可提供(gong)DJ41Y-160P低(di)(di)(di)溫(wen)(wen)(wen)高(gao)(gao)壓(ya)截(jie)(jie)(jie)(jie)止(zhi)(zhi)(zhi)閥(fa)(fa)(fa)價格(ge),DJ41Y-160P低(di)(di)(di)溫(wen)(wen)(wen)高(gao)(gao)壓(ya)截(jie)(jie)(jie)(jie)止(zhi)(zhi)(zhi)閥(fa)(fa)(fa)說明書,DJ41Y-160P低(di)(di)(di)溫(wen)(wen)(wen)高(gao)(gao)壓(ya)截(jie)(jie)(jie)(jie)止(zhi)(zhi)(zhi)閥(fa)(fa)(fa)實物圖(tu),DJ41Y-160P低(di)(di)(di)溫(wen)(wen)(wen)高(gao)(gao)壓(ya)截(jie)(jie)(jie)(jie)止(zhi)(zhi)(zhi)閥(fa)(fa)(fa)結構圖(tu),DJ41Y-160P低(di)(di)(di)溫(wen)(wen)(wen)高(gao)(gao)壓(ya)截(jie)(jie)(jie)(jie)止(zhi)(zhi)(zhi)閥(fa)(fa)(fa)外形尺寸(cun),DJ41Y-160P低(di)(di)(di)溫(wen)(wen)(wen)高(gao)(gao)壓(ya)截(jie)(jie)(jie)(jie)止(zhi)(zhi)(zhi)閥(fa)(fa)(fa)執行標準,DJ41Y-160P低(di)(di)(di)溫(wen)(wen)(wen)高(gao)(gao)壓(ya)截(jie)(jie)(jie)(jie)止(zhi)(zhi)(zhi)閥(fa)(fa)(fa)工作(zuo)原(yuan)理,DJ41Y-160P低(di)(di)(di)溫(wen)(wen)(wen)高(gao)(gao)壓(ya)截(jie)(jie)(jie)(jie)止(zhi)(zhi)(zhi)閥(fa)(fa)(fa)作(zuo)用特(te)點。
DJ41Y-160P低溫高壓截止閥產品規范
公稱壓力:16.0MPa
公稱通徑:15mm~50mm
適用介質:LO2、LN2、LAr、LNG、LC2H4等
適用溫度:-196~+80℃
連接方式:法蘭
介質流向:由閥瓣下面向上流
DJ41Y-160P低溫高壓截止閥主要零部件材料
閥體、閥蓋、閥瓣、閥桿:不銹鋼、閥蓋、閥瓣、閥桿:不銹鋼
填料:PTFE
密封圈:紫銅
閥瓣:堆焊司太立合金
產品型號 | DJ41Y-160P低溫高壓截止閥 | 重 量 (kg) | |||||||||||
產品代號 | 通徑 DN(mm) | 尺寸(mm) | |||||||||||
A | H1 | H2 | D | D1 | D2 | D6 | Z-d | b | f | D0 | |||
722J15AD2C3 | 15 | 170 | 320 | 310 | 110 | 75 | 55 | 40 | 4-18 | 24 | 2 | 250 | 9.7 |
722J20AD2C3 | 20 | 190 | 365 | 350 | 130 | 90 | 62 | 51 | 4-23 | 26 | 2 | 250 | 11.9 |
722J25AD2C3 | 25 | 210 | 375 | 360 | 140 | 100 | 72 | 58 | 4-23 | 28 | 2 | 350 | 13.8 |
722J40AD2C3 | 40 | 260 | 490 | 470 | 175 | 125 | 92 | 76 | 4-27 | 32 | 3 | 450 | 28.1 |
722J50AD2C3 | 50 | 300 | 530 | 500 | 215 | 165 | 132 | 88 | 8-25 | 36 | 3 | 650 | 38.5 |
